GW1NS-4
Features
- MIPI CSI/DSI RX & TX with fully integrated MIPI DPHY
- Hardcore ARM CortexM3
- SecureFPGA using SRAM PUF Technology
- GoAI 2.0 High Performance, Low Cost, Low Power Edge AI Solution
- On-chip pSRAM Memory 64Mb
- User Flash 256Kb
GW1NS-4 Architecture Overview (Figure 1)
GW1NS-4 Architecture Overview (Figure 2)
GW1NS-4 Family Table
| Parameter | GW1NS-4 | GW1NS-4C |
| LUT4 | 4,608 | 4,608 |
| FF | 3,456 | 3,456 |
| B-SRAM bits | 180K | 180K |
| B-SRAM quantity | 10 | 10 |
| 18 X 18 Multiplier | 16 | 16 |
| S-SRAM bits | - | - |
| User Flash bits | 256K | 256K |
| PLLs | 2 | 2 |
| OSC | 1,+/- 5% accuracy | 1,+/- 5% accuracy |
| Hard Core Processor | - | Cortex-M3 |
| USB PHY | - | - |
| ADC Channels | - | - |
| I/O Banks | 4 | 4 |
| Max. User I/O | 106 | 106 |
| Core Voltage | 1.2V | 1.2V |
Package Options with Max I/O (Refer to the latest datasheet for details)
| Package | Pitch(mm) | Size(mm) | GW1NS-4 | GW1NS-4C |
| CS36 | 0.4 | 2.5 x 2.5 | - | - |
| CS49 | 0.4 | 2.9 x 2.9 | 42(8) | 42(8) |
| MG64 | 0.5 | 4.2 x 4.2 | 57(8) | 57(8) |
| QN32 | 0.5 | 5 x 5 | - | - |
| QN32U | 0.5 | 5 x 5 | - | - |
| QN48 | 0.4 | 6 x 6 | 38(4) | 38(4) |
| LQ144 | 0.5 | 20 x 20 | - | - |
GW1NS-4 Development Board
For further details, please click here to visit.
To request for sample/ development boards, please click here to visit GoAI web page. (insert GoAI page link)
GW1NS4 documents
- GW1NS series of FPGA Products Data Sheet
- GW1NSR series of FPGA Products Data sheet
